how to solve riccati equation in optimal control

3 min read 23-01-2025

how to solve riccati equation in optimal control

The Riccati equation is a crucial element in solving many optimal control problems. Understanding how to solve it is key to designing controllers that minimize cost functions while satisfying system constraints. This article explores different methods for solving the Riccati equation within the context of optimal control.

What is the Riccati Equation?

The Riccati equation, in its most common form in optimal control, is a matrix differential equation. It arises when applying dynamic programming or the maximum principle to linear-quadratic (LQ) optimal control problems. The general form is:

dP/dt = -P A - Aᵀ P + P B R⁻¹ Bᵀ P - Q

Where:

P(t): The solution, a symmetric matrix representing the cost-to-go.
A: The system dynamics matrix.
B: The input matrix.
Q: The state cost matrix (positive semi-definite).
R: The input cost matrix (positive definite).
ᵀ: Denotes the transpose of a matrix.

The boundary condition is typically a terminal condition, often P(T) = P_f, where T is the final time and P_f is the terminal cost matrix (often zero for infinite-horizon problems). Solving this equation for P(t) allows us to determine the optimal control law.

Methods for Solving the Riccati Equation

Several methods exist to solve the Riccati equation, each with its strengths and weaknesses:

1. Numerical Integration (for Finite-Horizon Problems)

For finite-horizon problems, numerical integration techniques are often employed. These methods approximate the solution by discretizing time and using iterative methods such as:

Runge-Kutta methods: These are widely used and offer good accuracy. However, they can be computationally expensive for high-dimensional systems.
Euler method: A simpler but less accurate method. Useful for quick estimations or when computational resources are limited.

The choice of method depends on the desired accuracy and computational cost. Sophisticated numerical integrators are available in software packages like MATLAB and Python's SciPy.

2. Analytical Solution (for Specific Cases)

In some cases, analytical solutions to the Riccati equation can be found. This usually occurs when the system matrices A, B, Q, and R have specific structures, such as being time-invariant and having specific eigenvalues. For instance, for time-invariant systems with specific properties, the algebraic Riccati equation (ARE) can sometimes be solved analytically.

3. Algebraic Riccati Equation (ARE) for Infinite-Horizon Problems

For infinite-horizon problems (T → ∞), the Riccati equation simplifies to the algebraic Riccati equation (ARE):

0 = -P A - Aᵀ P + P B R⁻¹ Bᵀ P - Q

Solving the ARE is generally more challenging than the differential Riccati equation. Several numerical methods exist:

Newton-Raphson iteration: This iterative method starts with an initial guess for P and refines it until convergence is reached.
Schur method: This method is based on the Schur decomposition of matrices and is generally more efficient and robust than the Newton-Raphson method, particularly for large-scale systems.

Software packages like MATLAB provide built-in functions for solving the ARE (are function in MATLAB).

Optimal Control Law

Once the Riccati equation is solved (either the differential or algebraic version), the optimal control law u*(t) can be obtained. For the linear-quadratic regulator (LQR) problem, it is given by:

u*(t) = -R⁻¹ Bᵀ P(t) x(t)

where x(t) is the state vector at time t. This feedback control law utilizes the solution P(t) to determine the optimal control input at each time instant.

Example: A Simple LQR Problem

Consider a simple system with:

A = 1
B = 1
Q = 1
R = 1

For an infinite-horizon problem, we need to solve the ARE:

0 = -2P + P² - 1

This quadratic equation can be solved analytically to find two solutions for P. However, only the positive definite solution is relevant for the optimal control problem. The optimal control law is then given by u*(t) = -P x(t).

Conclusion

Solving the Riccati equation is fundamental to optimal control theory. Choosing the right method depends on the problem's specifics – finite or infinite horizon, system characteristics, and computational constraints. Numerical methods are generally preferred for complex systems, while analytical solutions are possible for simpler cases. Modern control systems software provides efficient tools for solving these equations. Understanding and applying these methods is crucial for designing effective and optimal control systems.
